產品詳情
|
型號 Bearing Type |
主要尺寸Dimension |
軸肩尺寸Shoulder Height |
基本額定載（徑向）Basic Load Rating （Radial） |
質量Weight |
||||||
內徑Inner Ring |
外徑Outer Ring |
滾子節(jié)圓直徑Roller Pitch Diameter |
高度Height |
倒角Chamfer |
Cr |
Cor |
||||
d |
D |
Dpw |
B B1 |
rmin |
ds |
Dh |
kN |
kN |
kg |
|
RB2008 |
20 |
36 |
27 |
8 |
0.5 |
23.5 |
30.5 |
3.23 |
3.1 |
0.04 |
RB2508 |
25 |
41 |
32 |
8 |
0.5 |
28.5 |
35.5 |
3.63 |
3.83 |
0.05 |
RB 3010 |
30 |
55 |
41.5 |
10 |
0.6 |
37 |
47 |
7.35 |
8.36 |
0.12 |
RB 3510 |
35 |
60 |
46.5 |
10 |
0.6 |
41 |
51.5 |
7.64 |
9.12 |
0.13 |
RB 4010 |
40 |
65 |
51.5 |
10 |
0.6 |
47.5 |
57.5 |
8.33 |
10.6 |
0.16 |
RB 4510 |
45 |
70 |
56.5 |
10 |
0.6 |
51 |
61.5 |
8.62 |
11.3 |
0.17 |
RB 5013 |
50 |
80 |
64 |
13 |
0.6 |
57.4 |
72 |
16.7 |
20.9 |
0.27 |
RB 6013 |
60 |
90 |
74 |
13 |
0.6 |
68 |
82 |
18 |
24.3 |
0.3 |
RB 7013 |
70 |
100 |
84 |
13 |
0.6 |
78 |
92 |
19.4 |
27.7 |
0.35 |
RB 8016 |
80 |
120 |
98 |
16 |
0.6 |
91 |
111 |
30.1 |
42.1 |
0.7 |
RB 9016 |
90 |
130 |
108 |
16 |
1 |
98 |
118 |
31.4 |
45.3 |
0.75 |
RB 10016 |
100 |
140 |
119.3 |
16 |
1 |
109 |
129 |
31.7 |
48.6 |
0.83 |
RB 10020 |
100 |
150 |
123 |
20 |
1 |
113 |
133 |
33.1 |
50.9 |
1.45 |
RB 11012 |
110 |
135 |
121.8 |
12 |
0.6 |
117 |
127 |
12.5 |
24.1 |
0.4 |
RB 11015 |
110 |
145 |
126.5 |
15 |
0.6 |
122 |
136 |
23.7 |
41.5 |
0.75 |
RB 11020 |
110 |
160 |
133 |
20 |
1 |
120 |
143 |
34 |
54 |
1.56 |
RB 12016 |
120 |
150 |
134.2 |
16 |
0.6 |
127 |
141 |
24.2 |
43.2 |
0.72 |
RB 12025 |
120 |
180 |
148.7 |
25 |
1.5 |
133 |
164 |
66.9 |
100 |
2.62 |
RB 13015 |
130 |
160 |
144.5 |
15 |
0.6 |
137 |
152 |
25 |
46.7 |
0.72 |
RB 13025 |
130 |
190 |
158 |
25 |
1.5 |
143 |
174 |
69.5 |
107 |
2.82 |
|
型號 Bearing Type |
主要尺寸Dimension |
軸肩尺寸 Shoulder Height |
基本額定載荷（徑向）Basic Load Rating （Radial） |
質量Weight |
||||||
內徑Inner Ring |
外徑Outer Ring |
滾子節(jié)圓直徑Roller Pitch Diameter |
高度Height |
倒角Chamfer |
Cr |
Cor |
||||
d |
D |
Dpw |
B B1 |
rmin |
ds |
Dh |
kN |
kN |
kg |
|
| ||||||||||
